140LM/W Trunnion 480V 450W LED Shoebox Pole Light 4000K
Product Details:
| Place of Origin: | China |
| Brand Name: | LEDSION |
| Certification: | UL, DLC |
| Model Number: | LS-7GESBV450WCT3B1-50 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Carton package, 1pcs/CTN, packing size: 29*15*6inch，weight: 20lbs |
| Delivery Time: | 1-2 days |
| Payment Terms: | T/T, CC, PP, Check |
| Supply Ability: | 500pcs/week |
|
Detail Information |
|||
| Product Name: | With Trunnion LED Area Lights | Power: | 450W |
|---|---|---|---|
| Light Source: | Seoul SMD3030 (462pcs) | Efficacy: | 140LM/W |
| Lamp Luminous Efficiency(lm/w): | 58500LM | Ip Rating: | IP65 |
| Working Temperature(℃): | -40 - 50℃ | Color Temperature(cct): | 5000K，4000K 5700K Available |
| Beam Angle: | 150*85 Degree | LED Driver: | Meanwell HLG-240H-48B*2PCS |
| Input Voltage(v): | 200-480Vac | Application: | Parking Lot,square, Street |
| Warranty(year): | 5 Years | Certification: | UL, DLC |
| High Light: | LEDSION 450W led shoebox pole light,LEDSION 4000K led shoebox pole light,LEDSION Trunnion 480 volt led parking lot lights |
||
Product Description
Trunion 480V 450W LED Area Light With 5 Years Warranty Brown Housing Color For Sport Lighting
High quality Brown 100W LED Shobox Lights in our USA Stock, With UL certification and DLC certification and 5 years warranty. There are 120V 480V and 3 types of Mounts(Slip Fitter/ Direct Mount/Yoke Mount) for you choose. What’s More we can arrange the shipment within 24 hours. If you like, the Photocell and motion sensor are achievable.
LED Shoebox Light Features:
LED Shoebox Light adopted optical light distribution, that is no glare, no light pollution, highly directional light and more even luminous beam.
1. Module lens design make the lamp with well suited lighting distributing for LED parking lot lighting.
2. Hollow out heat sink design make the lamp weight lighter and have good heat dissipation.
3. 5 kinds of installation brackets.
4. Good-looking appearance. lamp luminous efficiency reaches 140lm/w.
5. Lighting distribution curve: Type Ⅲ
6. Can be with photocell sensor and motion sensor.
Applications:
- School playground.
- Outdoor packing area.
- Tennis court, football court, basketball cout.
- Community leisure entertainment plaza, road lamp etc.
Specifications:
| Input Power | 450W |
| Lumen | 54000-60750LM |
| Lumen Efficacy | 120-135LM/W |
| Color Temperature | 4000K, 4500K, 5000K, 5700K |
| CRI | >70 |
| Viewing Angle | 150*85 Degree(Type Ⅲ) |
| Input Voltage | 200-480Vac 50/60Hz |
| PF | ≥0.9 |
| THD | ≤20% |
| Driver Model | Meanwell HLG-240H-48B*2PCS |
| Optional Accessory | Photocell Surge protector Motion sensor |
| LED Brand | SEOUL |
| LED Type | SMD3030 |
| LED QTY | 462 PCS |
| Housing | Aluminum |
| Housing Color | Black / Brown/white/Customized |
| Waterproof Rating | WET(IP65) |
| Operating Temperature | -40℃ TO 45℃ |
| Operating Humidity | 10％-90％ RH |
| Storage Temperature | -40℃ TO 80℃ |
| Storage Humidity | 10％-95％ RH |
| Warranty Time | 5 Years |
Product Dimension (mm):
AM
DM
YM
Packing:
| Stent Type | Lamps Net Weight | Size | Qty/ Carton | Weight/ Carton |
| AM | 11.5 KG | 1015x 395 x 165mm | 1 | 12.7KG |
| DM | 12KG | 1015 x 395 x 165mm | 1 | 13.2 KG |
| YM | 11.2KG | 1015 x 395 x 165mm | 1 | 12.4KG |
Dallas warehouse introduction:
Ledsion Lighting have its own warehouse in the United States, Located in Dallas, TX 75247. Warehouse area up to 50,000 square feet.
We have professional logistic team and after-saels service team there. Can help you to ship out the goods in the same day and provide high quality after-sales service.
